Khoom keeb kwm
Lub evolution ntawm integrated dynamic scanner PCBA zoo raws li kev loj hlob ntawm optical sensing, microelectronics thiab digital teeb liab ua technologies.
Thaum Ntxov (1980s-thaum xyoo 1990): Cov khoom siv scanning yog qhov loj, PCBA tsuas yog lub luag haujlwm rau kev ua cov teeb liab pib, thiab daim ntawv thov kev siv tshuaj ntsuam xyuas muaj tsawg.
Kev sib koom ua ke pib (nruab nrab- mus rau- lig 1990s- thaum ntxov 21st century): CCD/CMOS thiab MCU txhim kho kev koom ua ke, PCBA integrates cov duab ua chips kom ua tau siab dua scanning ceev thiab daws teeb meem, thiab yog siv rau barcode paub.
Kev kub ceev thiab siab precision (thaum ntxov 21st caug xyoo-2010): DSP thiab FPGA tsav kev ua tau zoo leaps, PCBA ua cov ntaub ntawv loj thiab cov algorithms nyuaj, kev kub ceev interfaces txhawb tus ncej siab dua, thiab tau siv dav hauv tshuab pom thiab kho mob.
Intelligent miniaturization (2010 txog tam sim no): AI thiab IoT thev naus laus zis sib koom ua ke, PCBA nyiam me me, ntse, thiab qis - lub zog, thiab onboard AI accelerators txhawb nqa ntug, haum rau cov khoom siv nqa tau thiab kos.
Khoom specifications
Core processor: siab -kev ua tau zoo DSP, FPGA lossis ARM Cortex series.
Duab sensor interface: txhawb MIPI CSI-2, LVDS, thiab lwm yam.
Txhawb kev daws teeb meem: VGA-UHD
Scanning ceev / ncej tus nqi: 500 ntas / thib ob.
Cov ntaub ntawv interface: USB 3.0/3.1, Gigabit Ethernet, CoaXPress, thiab lwm yam; Tswj thiab teeb tsa: UART, SPI, I2C.
Cia: Onboard DDR SDRAM, NAND Flash.
Lub zog hluav taws xob: DC 5V - 12V.
Kev siv hluav taws xob: ob peb watts rau kaum tawm watts.
Loj: compact, xws li 100mm x 80mm.
Kev khiav hauj lwm kub: kev lag luam tus qauv, -20℃rau +70℃.
Cov haujlwm tshwj xeeb: kho vajtse ISP, tsis siv neeg kis / dawb tshuav, hloov pauv hloov pauv, ua rau I / O, tswj teeb pom kev hauv lub nkoj.
Cov lus qhia khoom
Kev koom ua ke kho vajtse: txuas fais fab mov, sib xws sensor, cov ntaub ntawv interface (xws li USB, network cable), ua teeb liab thiab kho qhov muag.
Kev txhim kho software thiab kev debugging: Nruab tus tsav tsheb, siv SDK / API rau kev txhim kho theem nrab kom ua tiav cov duab tau thiab ua tiav; hloov kho lub firmware thiab teeb tsa scanning tsis.
Lus Cim: Nyeem phau ntawv qhia, tsis txhob muaj av noo thiab kub ib puag ncig; anti- zoo li qub; xyuas kom ruaj khov fais fab mov.
Daim ntawv thov khoom
Integrated dynamic scanner PCBA yog dav siv nyob rau hauv cov xwm txheej uas yuav tsum tau tiag tiag - sij hawm, siab - ceev daim duab nrhiav thiab tsom xam:
Kev lag luam automation thiab lub zeem muag ntawm lub tshuab: kuaj pom qhov tsis zoo, kev tswj kom zoo, barcode / QR code nyeem ntawv, kev taw qhia neeg hlau.
Cov duab kho mob thiab biometrics: cov khoom siv kho mob, cov cuab yeej kho qhov muag (retina / iris scanning), biometrics (ntiv tes / ntsej muag / iris).
Kev txawj ntse kev thauj mus los thiab kev ruaj ntseg: daim ntawv tso cai daim ntawv lees paub, kev saib xyuas kev khiav tsheb, kev txheeb xyuas tus cwj pwm.
Cov neeg siv khoom siv hluav taws xob thiab cov khw muag khoom: cov khw muag khoom ntse, qee cov khoom siv AR / VR, 3D scanning reconstruction.
Printing thiab ntim: luam ntawv zoo soj ntsuam, ntim kev tshuaj ntsuam xyuas.
Peb cov khoom tsim muaj peev xwm
①Solfware Development
Peb cov software engineers muaj peev xwm txhim kho microcontroller thiab embedded software, muaj peev xwm ua kev tsim kho kom haum rau microcontroller tswj cov khoom, kos cov khoom ntse raws li peb cov neeg siv khoom xav tau rau cov khoom lag luam.Our software engineers muaj peev xwm txhim kho microcontroller thiab embedded software, muaj peev xwm ua kev tsim kho kom haum rau peb cov khoom lag luam, cov khoom lag luam zoo li microcontroller. xav tau cov khoom ua haujlwm.
②Hardware Circuit Development
Peb cov kws tsim khoom kho vajtse muaj peev xwm ua cov khoom siv hluav taws xob tsim kho hluav taws xob, cov khoom lag luam debugging, fectification thiab lwm yam haujlwm thaum tseem tuaj yeem tsim cov khoom siv hluav taws xob zoo ntawm nws tus kheej; Tsis tas li ntawd, lawv muaj ntau yam kev paub dhau los hauv cov khoom lag luam kom ua tau raws li cov ntaub ntawv pov thawj ntawm UL, CE, FCC thiab lwm yam.
③Apperance, Ntim Design Service
Raws li cov neeg siv khoom xav tau, peb muaj peev xwm muab tag nrho cov khoom tiav cov kev pab cuam deaign, nrog rau cov khoom tsim qauv, apperance tsim, ntim tsim, thiab lwm yam.
FAQ
Q1: Dab tsi yog qhov tsis xws luag hauv PCBA manufacturing?
A1: Cov teeb meem feem ntau suav nrog: cov txuas txuas txuas, cov pob qij txha txias, tombstoning (cov khoom nqa), cov khoom ploj, thiab cov khoom tsis raug. Cov no feem ntau kuaj pom siv AOI (Kev Tshawb Fawb Kev Kho Mob Tsis Zoo) thiab X-Ray kuaj.
Q2: Dab tsi yog lub luag haujlwm ntawm solder paste hauv PCBA?
A2: Solder paste yog qhov tseem ceeb rau kev txuas cov khoom rau PCB. Nws muaj cov khoom me me uas raug tshem tawm hauv flux, uas yaj thaum lub sij hawm reflow soldering los tsim cov hluav taws xob muaj zog thiab cov khoom siv sib txuas.
Q3: Qhov txawv ntawm SMT thiab THT hauv PCBA yog dab tsi?
A3: SMT (Nto Mount Technology) tso cov khoom ncaj qha mus rau PCB nto, thaum THT (Los ntawm -Qhov Tshuab) ntxig cov khoom ua rau hauv qhov tho qhov ua ntej soldering. SMT yog nrawm dua thiab compact dua, thaum THT muab cov khoom sib txuas ua ke zoo dua.
Q4: Dab tsi ib puag ncig cuam tshuam cuam tshuam rau PCBA kev ntseeg tau?
A4: Cov ntsiab lus tseem ceeb suav nrog: qhov kub thiab txias, av noo, kev co, plua plav, thiab tshuaj lom neeg raug. Cov txheej txheem tsim nyog thiab xaiv cov khoom siv (piv txwv li, siab-Tg PCBs) pab txhim kho cov kav ntev.
